| Quantity: | |
|---|---|
| Parameter | Value |
|---|---|
| Vacuum Degree | 98.8% |
| Working Temperature | -40°C ~ +80°C |
| Colors | Blue |
| Shape | Round |
| Transmission Medium | Compressed Air, Vacuum, Inert Gas |
| Working Pressure | 13 bar (-40~+80°C), 16 bar (-20~+60°C) |
| Material Features | Spraying Aluminum, SS, Copper, Engineering Plastic |
| Application | Air Condition, Automobile, Air Compressor |
| Alloy | Alloy |
| Specification | 5.8m Length, DN20-200 Optional |
| Leakage | No Leakage |
| Fire-Resistant | According to UL-90vo Standard |
| Diameter | 20 25 40 50 63 80 100 125 148 200 |
| Trademark | FSTPipe |
| Connection Type | Welding |
| Medium | Liquid, Fluids with Solid Particle, Gas |
| Origin | China |
FSTPipe's Blue Aluminum Alloy Pipe Elbow is designed for efficient fluid and gas transmission. The pipe elbow is made of durable spraying aluminum, stainless steel, copper, and engineering plastic. It is suitable for use with compressed air, vacuum, and inert gas. The working temperature ranges from -40ºC to +80ºC, ensuring versatility in different environments. It operates at pressures of 13 bar (for temperatures from -40ºC to +80ºC) and 16 bar (for -20ºC to +60ºC). The product is available in a variety of sizes, including diameters from 20 to 200 mm. The elbow pipe is designed for applications in air conditioning, automobiles, and air compressors. The material is fire-resistant according to UL-90vo standards. The product is leak-free, ensuring reliable performance in various systems. It is available in a 5.8-meter length, with DN20-200 size options. FSTPipe offers reliable welding connections for secure and long-lasting installation.
Seamless Extruded Aluminum Alloy Pipe: No leaks and secure connections for reliable performance.
Efficient Transmission: Smooth interior surface reduces pressure loss, enhancing energy efficiency.
Perfect Compatibility: Complete accessories for easy connections with internal threads, external threads, and flanges.
Simple and Fast Operation: No welding required, no complex training needed, and quick installation.
High Durability: Resistant to corrosion, fire, and heat, with a smooth appearance, suitable for harsh environments.
Maximum Flexibility: Can be disassembled and reused, adaptable to changes in factory settings and production lines.
Material Properties: Made from aluminum alloy, which is one-third the density of steel. Offers a balance of light weight and high pressure resistance.
Function: Designed for transporting dry, oil-free, and impurity-free compressed air. Ideal for use with air compressors, dryers, and similar equipment.
Pipe Specifications: Available in sizes ranging from DN20 to DN200 to suit various installation needs.
Working Pressure: Can withstand a working pressure of up to 16 bar for reliable performance.
Applicable Environments: Suitable for mildly corrosive, UV-exposed, outdoor environments, mechanical vibrations, temperature changes, and compressor oil environments.
Electronics: Used in the production and maintenance of electronic devices and systems.
Food Materials: Applied in food processing and packaging industries for safe and clean air transmission.
Tobacco Manufacturing: Ideal for use in tobacco production lines for efficient air handling.
Home Manufacturing: Used in HVAC systems and other home manufacturing processes.
New Energy: Supports systems in renewable energy sectors like solar and wind power.
Printing and Paper: Used in printing presses and paper manufacturing for stable airflow.
Clothing Manufacturing: Ensures efficient air movement in textile and garment factories.
Textile Dyeing: Used in textile dyeing facilities to maintain consistent air pressure.
Healthcare: Applied in medical facilities and equipment for air and gas transmission.
Machinery Manufacturing: Supports compressed air systems in machinery production.
Automotive and Parts: Used in automotive production and parts manufacturing for precise air control.
10-Year Quality Guarantee: From installation acceptance, any quality issues will be addressed with free replacements or repairs.
Exclusions:
Products or components outside the warranty period (unless extended warranty service is provided).
Products not installed according to supplier guidelines or outside their applicable scope.
Unauthorized installation, repair, modification, or disassembly.
